Home ProductsScintillator Detector

LaBr3 SiPM Scintillator Detector

China Kinheng Crystal Material (Shanghai) Co., Ltd. certification
I'm Online Chat Now

LaBr3 SiPM Scintillator Detector

LaBr3 SiPM Scintillator Detector
LaBr3 SiPM Scintillator Detector

Large Image :  LaBr3 SiPM Scintillator Detector

Product Details:
Place of Origin: China
Brand Name: Kinheng
Certification: ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: foam box
Delivery Time: 4-6 weeks
Payment Terms: T/T, Paypal
Supply Ability: 10000pcs/year

LaBr3 SiPM Scintillator Detector

Reflector: MgO Housing: Aluminum
Scintillator: NaI(Tl),CsI(Tl),GAGG,CeBr3,LaBr3 Crystal Size: 2 Inch
HV: 26~+31V Humidity: ≤70%
Signal Amplitude: -50mv Energy Resolution: <7.5%
High Light:

LaBr3 SiPM Scintillator Detector


Aluminum Housing Labr3 Detector


MgO Reflector Scintillator Detector

LaBr3 SiPM Scintillator detector


The LaBr3(Ce) detector is completely compatible with the signal processing electronics normally used with NaI(Tl) scintillation detectors. However, the performance of the LaBr3(Ce) device is superior to that of NaI(Tl) detectors. No adapters are required for direct connection of tube base preamplifiers or MCAs to the 14-pin PMT base. The better resolution, efficiency and relatively short decay time (16 ns) allow these detectors to be used with more complex spectra than scintillation detectors based on NaI(Tl) as well as in other applications previously thought to be too demanding for any scintillation detector.





S-1 S-2
Crystal size 1” 2”
SIPM 6x6mm 6x6mm
SIPM Numbers 1~4 1~16
Storage temperature -20 ~ 70℃ -20 ~ 70℃
Operation temperature -10~ 40℃ -10~ 40℃
HV 26~+31V 26~+31V
Scintillator NaI(Tl),CsI(Tl),GAGG,CeBr3,LaBr3 NaI(Tl),CsI(Tl),GAGG,CeBr3,LaBr3
Humidity ≤70% ≤70%
Signal Amplitude -50mv -50mv
Energy resolution <7.5% <7.5%


LaBr3 SiPM Scintillator Detector 0LaBr3 SiPM Scintillator Detector 1

                           S2 Dimension                                                                     S2 Connector



Radiation dose measurement

Energy measurement

Spectrum analysis

Nuclide identification


Product renderings:


LaBr3 SiPM Scintillator Detector 2

LaBr3 SiPM Scintillator Detector 3

LaBr3 SiPM Scintillator Detector 4




1.Q: Are you a factory manufacturer?

A: Yes ,we are manufacturer with 13 years experience in the scintillator crystal industry and supplied many famous brands with good quality and service.


2.Q:Where is your main market?

A:Europe, America, Asia.
