NaI (Tl) Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy

Description
Encapsulation: SS Housing Scintillator Available: NaI(Tl)
Size: 100x100x400mm,4"x4"x16" PMT: CR119
FWHM: 8% ~ 8.5% Storage Temperature: -20 ~ 70℃
Operation Temperature: 0~ 40℃ Warranty: One Year
Operation Humidity: ≤70%
High Light:

Nuclear Spectroscopy Scintillator Detector

,

SS Housing NaI Scintillation Detector

,

NaI Tl Detector 4"x4"x16"

NaI(Tl) Scintillation Detector 4"x4"x16" nuclear spectroscopy



High-quality Sodium Iodide crystal scintillators are available with a large variety of form factors and sizes. These detectors offer the best performance and resolution for your nuclear spectroscopy applications.

Size does matter. NaI crystals can be grown to large dimension and at relatively low cost. When increasing the diameter of the scintillator, the solid angle under which the detector "sees" the source also increases. This increases the detection efficiency.



Application:

Radiation dose measurement

Energy measurement

Spectrum analysis

Nuclide identification



Properties:



Model

Properties

SD-1 SD-2 SD-2L SD-4L
Crystal size 1” 2"&3" 50x100x400mm 100x100x400mm
PMT CR125 CR119 CR119 CR119
Storage Temperature -20 ~ 70℃ -20 ~ 70℃ -20 ~ 70℃ -20 ~ 70℃
Operation temperature 0~ 40℃ 0~ 40℃ 0~ 40℃ 0~ 40℃
HV 0~+1500V 0~+1500V 0~+1500V 0~+1500V
Scintillator

NaI(Tl)

NaI(Tl) NaI(Tl) NaI(Tl)
Operation Humidity ≤70% ≤70% ≤70% ≤70%
Energy resolution 6% ~ 8% 6% ~ 8% 7% ~ 8.5% 7% ~ 8.5%



 NaI (Tl)  Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy 0



                                                                          2" probe dimension



NaI (Tl)  Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy 1

                                                                               Pin Definition







Product shots:

NaI (Tl)  Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy 2

NaI (Tl)  Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy 3

NaI (Tl)  Scintillation Detector 4" X 4" X 16" Nuclear Spectroscopy 4





FAQ:

1.Q: Are you a factory manufacturer?

A: Yes ,we are manufacturer with 13 years experience in the scintillator crystal industry and supplied many famous brands with good quality and service.



2.Q:Where is your main market?

A:Europe, America, Asia.
