PET YSO Scintillation Crystal High Energy Physics Geologic Survey

Certification
China Kinheng Crystal Material (Shanghai) Co., Ltd. certification
I'm Online Chat Now

PET YSO Scintillation Crystal High Energy Physics Geologic Survey

PET YSO Scintillation Crystal High Energy Physics Geologic Survey
PET YSO Scintillation Crystal High Energy Physics Geologic Survey

Large Image :  PET YSO Scintillation Crystal High Energy Physics Geologic Survey

Product Details:
Place of Origin: China
Brand Name: Kinheng
Certification: ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: foam box
Delivery Time: 4-6 weeks
Payment Terms: T/T, Paypal
Supply Ability: 10000pcs/year

PET YSO Scintillation Crystal High Energy Physics Geologic Survey

Description
Material: Scintillator Crystal, Scintillator ,crystal Product Name: YSO:Ce
Chemical Formula: Y₂SiO₅:Ce Size: Customized
Atomic Number (Effective): 39 Wavelength (Max. Emission): 420nm
Wavelength Range: 350-700nm Refractive Index: 1.8 @420nm
Application: Nuclear Medical Imaging (PET)
High Light:

350nm Scintillator Crystal

,

PET YSO:Ce

,

Scintillator Crystal 420nm

High energy physics Geologic survey PET YSO Scintillation crystal



YSO(Ce) - Yttrium Orthosilicate:Cerium (Y₂SiO₅:Ce) - scintillation crystals are relatively bright, have an emission maximum at 420nm and are relatively fast with a decay time of c.70ns.



Properties:

Crystal System Monoclinic
Melting Poind(℃) 1980
Density(g/cm3) 4.44
Light yield(Photons/Kev) 30-32
Decay Time(ns) 70



Advantage:

Low background

No cleavage planes

Non-hygroscopic.

Good stopping power



Application:

Nuclear medical imaging (PET)

High energy physics

Geologic survey



Product shots:



PET YSO Scintillation Crystal High Energy Physics Geologic Survey 0



FAQ:

1. Q: Are you a factory manufacturer?

A: Yes ,we are manufacturer with 13 years experience in the scintillator crystal industry and supplied many famous brands with good quality and service.



2. Q: Where is your main market?

A: Europe, America, Asia.
